Buddy Phone for Full Face Mask, 2 Channels
The Buddy Phone® D2 is a digital, micro-miniature, ultrasonic transceiver allowing communication between two or more scuba divers and / or surface stations.
(Sold Separately, Does Not Include FFM)
Price range from $875.00 – $939.00
KEY FEATURES
Description
Using “Digital Signal Processing” (DSP) techniques, the Buddy Phone produces uncompromising speech clarity.The Buddy Phone® D2 differs from our standard Buddy Phone in that it is digitally controlled and has some fantastic features such as: a voice menu to guide you adjust your Volume, change from Channel A to Channel B, or put the Buddy Phone in a continuous voice transmission mode.
Voice Menu: When you submerge with a D2 Buddy Phone, you will hear the voice system say “Buddy Phone ON, frequency A (B), channel one (four), volume High (Medium, Low),” depending on the prior dive’s settings. Changing a setting is easy and can be done while underwater. Depress the Push-to-talk switch (PTT) three times quickly and hold the third depression until you hear “main menu – volume, channel, continuous transmit.” When you hear the main menu selections, simply depress the PTT to select one of the choices. The unit will make the selection and go back to the receive mode. If you don’t make a selection after the menu repeats twice, the D2 Buddy Phone goes out of the main selection menu and back to the receive mode (see operators manual for a more detailed explanation — note: continuous transmit mode allows the user to talk, hands free. This was requested by many movie makers and scientists who talk on camera often).
In all, this D2 Buddy Phone is State-of-the-Art and OTS technology at its best.
About Buddy Phone for Full Face Mask, 2 Channels
The Ocean Technology Systems (OTS) Buddy Phone D2 is a digital, micro-miniature, ultrasonic transceiver allowing communication between two or more scuba divers or surface stations. Using "Digital Signal Processing" (DSP) techniques, the Buddy Phone produces uncompromising speech clarity. The Buddy Phone D2 differs from OTS's standard Buddy Phone in that it is digitally controlled and has some fantastic new features such as: a voice menu to guide you adjust your Volume, change from channel A to Channel B or put the Buddy Phone in a continuous voice transmission mode.
Voice Menu: When you submerge with a D2 Buddy Phone, you will hear the voice system say "Buddy Phone ON, frequency A (B), channel one (four), volume High (Medium, Low)," depending on the prior dive's settings. Changing a setting is easy and can be done while underwater. Depress the Push-to-talk switch (PTT) three times quickly and hold the third depression until you hear "main menu - volume, channel, continuous transmit." When you hear the main menu selections, simply depress the PTT to select one of the choices. The unit will make the selection and go back to the receive mode. If you don't make a selection after the menu repeats twice, the D2 Buddy Phone goes out of the main selection menu and back to the receive mode (see operators manual for a more detail explanation. Note: continuous transmit mode allows the user to talk, hands free. This was requested by many movie makers and scientist who talk on camera often).
The D2 Buddy Phone has a Nominal Range of 165' to 1640.4' (50 to 500 meters), Transmit Output Power of 0.5 watts PEP, uses Standard Frequency Peak Envelope Power (PEP): Recall & Tone: Frequency A (Channel 1) 32.768 kHz USB, Frequency B (Channel 4) 31.250 kHz with an Audio Bandwidth of 300 to 3,000 Hz. The D2 Buddy Phones has an Automatic Gain Control greater than 80 dB, Ceramic Earphones with a Ceramic Cylinder Transducer, Uses the ME-16R Hot-Mic (Dynamic) or Super Mic (Standard) (Ceramic), is Powered by a 9 Volt Alkaline Battery (not included) with a Operational Depth of 130' (30 meters). The Buddy Phone is designed to be used with the OTS Guardian Full Face Mask (see SKU's: OTSGFM, OTSGFMBD2, OTSGFMEM, OTSSFFM). The Buddy Phones come with an owner's manual.
Warranty Information
This product has a limited warranty of 12 months.
800-550-1984
Buddy Phone for Full Face Mask, 2 Channels Features
- Buddy Phone for Guardian 2 Channels:
- Buddy Phone D2 System;
- Fits: OTS Guardian Full Face Masks (see SKU's: OTSGFM, OTSGFMBD2, OTSGFMEM, OTSSFFM)
- Digital, Micro-Miniature, Ultrasonic Transceiver
- Allows: Communication between Two-or-More Scuba Divers or Surface Stations
- Uses: "Digital Signal Processing" (DSP) Techniques
- Uncompromising Speech Clarity
- Digitally Controlled:
Voice Menu;
Adjust Volume
Change Channels
Continuous Voice Transmission
Submerge Hear Buddy Phone ON
Frequency A (B), Channel 1 (4)
Volume High (Medium, Low) - Easy to Change Settings:
Depress the Push-to-Talk Switch (PTT) 3x Hold and Hear "Main Menu - Volume, Channel, Continuous Transmit" - Simply Depress the PTT to Select Choices
- Note: Continuous Transmit Mode for Hands Free Talking
- Nominal Range: 165' to 1640.4' (50 to 500 meters)
- Transmission Type: Ultrasound: Using Upper Single Sideband (USB)
- Transmit Output Power: 0.5 watts Peak Envelope Power
- Standard Frequency Peak Envelope Power (PEP):½
Recall & Tone: Frequency A (Channel 1) 32.768 kHz USB½
Frequency B (Channel 4) 31.250 kHz - Audio Bandwidth: 300 to 3,000 Hz
- Automatic Gain Control: Greater than 80 dB
- Ceramic Earphones with a Ceramic Cylinder Transducer
- Uses the ME-16R Hot-Mic (Dynamic) or Super Mic (Standard) (Ceramic)
- Power: 9 Volt Alkaline Battery (not included)
- Operational Depth of 130' (30 meters)
- Owner's Manual
Specifications
Nominal Range | 50 to 500 meters depending on sea conditions & noise levels. |
---|---|
Transmission Type | Ultrasound using upper single sideband (USB) |
Transmit Output Power | 0.5 watts PEP |
Standard Frequency (PEP) | Recall & tone: Freq. A (Channel 1): 32.768 kHz USB Freq. B (Channel 4): 31.250 kHz |
Audio Bandwidth | 300 to 3,000 Hz |
Automatic Gain Control | Greater than 80 dB |
Earphone | Ceramic |
Microphone | High Quality Microphone |
Transducer | Ceramic cylinder |
Battery Type: | Alkaline 9V. Batteries not included |
Maximum Operating Depth | 130 feet in sea water (fsw) |
Weight in Air | 8.1 o |
